We provide total solutions for key equipment of refinery, gas processing and petrochemical plants, ranging from large-scale towers and columns, heavy wall reactors to various kinds of heat exchangers and pressure vessels.

Tower & Column

Doosan E&C is a global company in the field of large-scale towers and columns with having a track record of successful delivery of 1,500-ton wash tower.

This is a high vertical-type with nozzle or trays that distillates or rectifies compounds utilizing a difference in the boiling point.

PERFORMANCE

Weight: Up To 3,000 Ton
Max Length: 100m
Max Diameter: 15m
Max Thickness: 300mm
Material: 2.25 Cr - 1 Mo (W/T SS WO/CLAD)
1.25 Cr - 1/2 Mo (W/T SS WO/CLAD)
Carbon Steel (W/T SS WO/CLAD)
304L
304L/304 Dual Grade
316
316L/316 Dual Grade
Design Code: ASME Section VIII Div. 1 & 2, AD-Merkblatter, PD5500, GOST
Licensor: CLG, UOP, Haldor Topsoe, Exxon Mobil, Axens, Foster Wheeler, BP, Shell, Saipem, Ammonia Casale, ConocoPhilips, Toyo, CB&I, Linde, Prosernat, Lurgi, Uhde, KBR, Davy Process, Technip etc.

Reactor

Doosan E&C is fully equipped to manufacture various types of reactors, including the ones made out of vanadium, and ensures customer satisfaction with top-notch quality and competitive pricing.

Reactors are used to mix two or more types of substances or shorten the reaction time and stabilize composition by increasing the density of contact between substances in floating granules, solutions, or chemical reactions.

PERFORMANCE

Weight: Up To 1,500 Ton
Max Length: 100m
Max Diameter: 10m
Max Thickness: 300mm
Material: 2.25 Cr - 1 Mo (W/T SS WO/CLAD)
2.25 Cr - 1 Mo Enhanced (W/T SS WO/CLAD)
2.25 Cr - 1 Mo 0.25 V Modified (W/T SS WO/CLAD)
1.25 Cr - 1/2 Mo (W/T SS WO/CLAD)
1 Cr - 1/2 Mo (W/T SS WO/CLAD)
Carbon Steel (W/T SS WO/CLAD)
Design Code: ASME Section VIII Div. 1 & 2, AD-Merkblatter, PD5500, EN13445, GOST
Licensor: CLG, UOP, Haldor Topsoe, Exxon Mobil, Axens, Foster Wheeler, BP, Shell, Saipem, Ammonia Casale, ConocoPhilips, Toyo, CB&I, Linde, Prosernat, Lurgi, Uhde, KBR, Davy Process, Technip etc.

Heat Exchanger

Doosan E&C specializes in manufacturing shell & tube heat exchangers that are essential to chemical plants and propane evaporators required in LNG plants.

Designed to transfer heat between substances, heat exchangers which come in types of multi-cyliner, dual tubular, multi-tubular, and air-cooled are widely used in petroleum refineries, petrochemical industries, and general chemical industries.

PERFORMANCE

Weight: Up To 400 Ton
Max Length: 30m
Max Diameter: 8m
Max Thickness: 300mm
Material: 2.25 Cr - 1 Mo (W/T SS WO/CLAD)
1.25 Cr - 1/2 Mo (W/T SS WO/CLAD)
2.25 Cr - 1 Mo 0.25 V Modified (W/T SS WO/CLAD)
2.25 Cr - 1 Mo Enhanced (W/T SS WO/CLAD)
Carbon Steel (W/T SS WO/CLAD)
304L
304L/304 Dual Grade
316
316L/316 Dual Grade
Duplex
Ni Alloy
Titanium
Design Code: ASME Section VIII Div. 1 & 2, AD-Merkblatter, PD5500, GOST
Licensor: CLG, UOP, Haldor Topsoe, Exxon Mobil, Axens, Foster Wheeler, BP, Shell, Saipem, Ammonia Casale, ConocoPhilips, Toyo, CB&I, Linde, Prosernat, Lurgi, Uhde, KBR, Davy Process, Technip etc.

Pressure Vessel

Doosan E&C manufactures pressure vessels of various materials and sizes, being the world’s largest producer. Furthermore, to secure competitiveness of small- and mid-sized equipment, Doosan VINA (based in Vietnam) is in operations.

Pressure vessels are closed containers designed for the storage, reaction, and separation of fluid (liquid or gas) to withstand the pressure of internal fluid.

PERFORMANCE

Weight: Up To 1,500 Ton
Max Length: 100m
Max Diameter: 15m
Max Thickness: 300mm
Material: 2.25 Cr - 1 Mo (W/T SS WO/CLAD)
1.25 Cr - 1/2 Mo (W/T SS WO/CLAD)
Carbon Steel (WT SS WO/CLAD)
304L
304L/304 Dual Grade
316
316L/316 Dual Grade
Duplex
Ni Alloy
Titanium
Design Code: ASME Section VIII Div. 1 & 2, AD-Merkblatter, PD5500, GOST
Licensor: CLG, UOP, Haldor Topsoe, Exxon Mobil, Axens, Foster Wheeler, BP, Shell, Saipem, Ammonia Casale, ConocoPhilips, Toyo, CB&I, Linde, Prosernat, Lurgi, Uhde, KBR, Davy Process, Technip etc.
